Low sorting limit: Effective sorting particle size can reach 1mm.
High sorting accuracy: Ep value: 0.12-0.23g/cm3
Sorting particle size: Adjustable upper limit from 30 to 6mm
High product yield: Except for discharged gangue, all products can be recovered.
Good environmental performance: No mud formation is produced, and all coal powder can be recovered, resulting in good environmental performance.
Low product moisture: Compared with water separation process, the clean coal product has lower moisture and higher calorific value.
| Model | Processing Capacity（t/h） | Feed Particle Size（mm） | Equipment Power（Kw） | External Dimensions (Length × Width × Height)m |
| FGX100 | 85-100 | 30-0 | 240 | 9.8 × 8.5 × 6.2 |
| FGX150 | 135-150 | 30-0 | 345 | 17.2 × 12.2 × 8.9 |
| FGX200 | 180-205 | 50-0 | 416 | 16 × 12.2 × 8.9 |
| FGX300 | 270-310 | 50-0 | 810 | 21.1 × 16.4 × 11.2 |
| FGX400 | 360-410 | 50-0 | 1175 | 23.5 × 22.3 × 12 |
| FGX600 | 540-620 | 50-0 | 1370 | 27.4 × 24.5 × 12 |
| FGX800 | 720-820 | 50-0 | 810 | 21.1 × 16.4 × 11.2 |
