◎ Using a fully dry separation technology, coal and gangue can be accurately separated without water. The separation accuracy exceeds that of water washing (jigging) and can operate stably for a long time.
◎ This equipment uses X-ray sensing technology to identify differences in material composition, effectively solving the problems of high water consumption and environmental pollution in traditional water washing processes. It is suitable for coal washing scenarios in arid and water-scarce areas or with high environmental protection requirements, providing a new solution for the clean and efficient utilization of coal.
◎ Core components are original products from internationally renowned brands, ensuring high reliability and long lifespan.
◎ Utilizes advanced algorithms in collaboration with RWTH Aachen University in Germany, resulting in fast processing speed and high accuracy.
◎ User-friendly interface; sorting parameters can be flexibly adjusted according to sorting requirements, making operation simple.
◎ The equipment can be centrally controlled, achieving a high degree of automation.
◎ Material conveying speed can reach 3.5m/s, providing a large processing capacity.
◎ Equipped with a built-in uniform material distribution device, effectively preventing mis-blowing caused by material accumulation.
Precise Identification and Leading Sorting Accuracy
Innovatively employing charge-coupled device (CCD) time-delay aggregation technology optimizes X-ray transmission identification accuracy and adapts to multi-sensor combination schemes;
Key Indicators: Gangue with Coal Content 1-3%, Coal with Gangue Content 3-5%, accuracy approaching that of shallow trough sorting, far exceeding that of dry sorting equipment such as moving screens and jigs.
Rapid detection and outstanding processing efficiency
Detection efficiency: Acquires 1 million spectra per second, detects 40,000 ore pieces, with millisecond-level response time for irradiation-injection decisions;
Wide particle size adaptability: Processes 25-300mm raw coal (maximum feed 400mm), covering 25-50mm and 100-300mm ranges;
High capacity: Maximum single-unit processing capacity of 380t/h (XRT-4000 model), the 2.4m wide model processes 10-300mm ore up to 300t/h, a single unit can meet the needs of an 8Mt/a coal preparation plant.
Low energy consumption, worry-free investment and operation & maintenance
Low energy consumption: Single unit (e.g., XRT1200) installed power 140kW, energy consumption per ton of coal < 2kW;
Advantages: Low investment, low operating cost, short construction period, simple system structure, and fewer equipment units required.
Intelligent and reliable, comprehensive safety protection
Intelligent features: Supports system self-learning and fault self-diagnosis functions;
Dust removal design: Integrated cartridge dust collector, anti-static filter media, 0.5μm dust removal efficiency ≥ 99.9%, filtration velocity ≤ 1.2m/min;
Radiation safety: Class III radiation device (non-radioactive source), fully sealed lead plate shielding, radiation intensity around the equipment < 2.5μSv/h (approximately 1μSv/h at 1m), meeting international radiation explosion protection standards.
Smart cloud platform
Real-time statistical analysis of material operation indicators, intelligent online monitoring of operating status.
Modular design
Convenient and quick installation and maintenance.
Table 1 Selection Table for 50-300mm XRT Intelligent Sensor Sorting Machine
| Model | Fabric belt width mm | Processing particle size mm | Processing capacity t/h | Radiation dose rate μSv/h |
| XRT-1200Ｍ | 1200 | 50～300 | 80～120 | ≤2.5 |
| XRT-1600Ｍ | 1600 | 120～160 | ≤2.5 | |
| XRT-2000Ｍ | 2000 | 160～200 | ≤2.5 | |
| XRT-2400Ｍ | 2400 | 200～250 | ≤2.5 | |
| XRT-3200Ｍ | 3200 | 240～360 | ≤2.5 | |
| XRT-4000Ｍ | 4000 | 280～460 | ≤2.5 | |
| Note: Calculated based on a 25% yield of 50-300mm gangue. Actual mineral processing capacity depends on ore particle size, density, and feeding method. | ||||
Table 2 Selection Table for 25-100mm XRT Intelligent Sensor Sorting Machine
| Model | Fabric Belt Width mm | Processing Particle Size mm | Processing Capacity t/h | Radiation Dose Rate μSv/h |
| XRT-1200Ｍ | 1200 | 25～100 | 60～72 | ≤2.5 |
| XRT-1600M | 1600 | 84～96 | ≤2.5 | |
| XRT-2000M | 2000 | 108～120 | ≤2.5 | |
| XRT-2400M | 2400 | 126～150 | ≤2.5 | |
| XRT-3200M | 3200 | 192～216 | ≤2.5 | |
| XRT-4000M | 4000 | 252～276 | ≤2.5 | |
| Note: Calculated based on a 30% yield of 25-100mm gangue. Actual mineral processing capacity depends on ore particle size, density, and feeding method. | ||||
