◎ Use the intelligent gantry crane mode for rail trusses.

◎ Equipped with Φ160 electromagnets, each set includes 3 units capable of lifting 10-15KG steel balls. A weighing module is installed above each electromagnet to individually measure the weight of each lifted ball.

◎ The ball charging can be done in quantifiable time segments.

◎ The ball charging amount can be adjusted based on the feed rate, automatically added according to the ore-to-ball consumption ratio, or determined by the power capacity of the ball mill.

◎ Ball charging accuracy: ±1%.

◎ Recordable ball loading workload: daily, monthly, yearly, total, and shift-based, with data storage to generate electronic spreadsheets and transmit to the central control system.

◎ Equipped with dual mechanical arms, one operational and one standby, featuring self-diagnosis for mechanical arm failures and the capability to automatically activate the standby arm under certain conditions.

◎ With network connectivity, it supports remote monitoring, allowing users to check the ball feeder status, modify ball feeding parameters, and receive alerts for abnormal device information or fault alarms via mobile apps or WeChat mini-programs.

◎ Equipped with remote communication capabilities, ball data sharing, and configurable integration with the central control system.

◎ The parameter setting and extraction are performed using a high-reliability touch screen display, with all parameters adjustable, including production display and zero-reset settings.

◎ The touchscreen will indicate the specific fault location.
